8) Ohlins TTX Fork Cartridge Kits 30mm & 25mm

1)

Above Ohlins 30mm kit with springs 2015-2016 Yamaha R1 , 2017 R1~ FGK235.

Ohlins TTX  Fork Cartridge Kits

2)

Ohlins has some excellent application specific Cartridge Kits and Spring kits.

No machining required and are 100% reversible.

This example has:

30mm cartridge and pistons, external adjustable spring preload (aprox. 18 turns) , Adjustable Compression (aprox. 24 Clicks), Adjustable Rebound (aprox. 24 clicks), everything adjusts at top caps for convenience.

3)

This pic above shows this example with Anti Bottoming Hydraulic Cones and Spring set.

4)

The manufacture has information on what suspension fluid and how much to use within a range.

5)

The Above Pic ( FAR LEFT ARROWS ) Shows a Sample Standard OEM stamped steel Non adjustable cartridge like from the 1970’s……. (Only shame is That’s What Comes in Some Applications on new bikes this year!) .

That’s why the Ohlins 30mm Cartridge  and Ohlins Spring set has been so popular because it’s very similar to what comes in the whole Ohlins Road Track 43 Forks.
